Analog Auto Switch, Display Sensor Monitor

The D-MH1 series outputs the analog voltage according to the actuator stroke position. The D-MH1 offers both analog auto switch and/or display sensor Monitor, which allows for remote detection position setting. Labor is reduced by eliminating the need to fine-tune the switch mounting position and easy adjustment even in narrow place and moving parts By selecting either the 3-setting mode or the 2-setting mode, various uses can be accommodated and productivity can be improved.

  • Analog auto switch
  • Max. 3 position points
  • Analog voltage output: 1 to 5 V
  • Detection of gripper finger wear
  • Minimized lead-wire disconnection risk
